Fujitsu AOU36RLXFZ Service Manual

se a wireless remote control, the lamp
p
hoto detector unit will output error codes
of blinking patterns.
se a wired type remote control, error
w
ill appear on the remote control display.
e
lamp blinking patterns and error codes
a
ble. An error display is displayed only
r
unning.
O
R UNIT
W
IRED REMOTE CONTROL
(1)
(5)
Check run unfinished
(2)
(1)
Unit number or Refrigerant circuit address setting err
o
[Simultaneous Multi]
(2) (2)
Indoor unit capacity error
(2) (3)
Combination error
(2)
(4)
Connection unit number error (indoor slave unit)•
[Simultaneous Multi]
Connection unit number error (indoor unit or branch •
[Flexible Multi]
(2)
(7)
Master unit, slave unit set-up error [Simultaneous M
u
(3)
(2)
Indoor unit PCB model information error
(3) (5)
Manual auto switch error
(4) (1)
Inlet air temp. sensor error
(4) (2)
Indoor unit Heat Ex. Middle temp. sensor error
(5)
(1)
Indoor unit fan motor error
(5)
(3)
Drain pump error
(5) (7)
Damper error
(5) (15)
Indoor unit error
(6)
(2)
Outdoor unit main PCB model information error or
communication error
(6) (3)
Inverter error
(6)
(4)
Active filter error, PFC circuit error
(6) (5)
Trip terminal L error
(6)
(10)
Display PCB microcomputers communication error
(7)
(1)
Discharge temp. sensor error
(7) (2)
Compressor temp. sensor error
(7) (3)
Outdoor unit Heat Ex. liquid temp. sensor error
(7) (4)
Outdoor temp. sensor error
(7)
(5)
Suction Gas temp. sensor error
(7) (6)
2-way valve temp. sensor error•
3-way valve temp. sensor error•
(7) (7)
Heat sink temp. sensor error
(8) (2)
Sub-cool Heat Ex. gas inlet temp.sennsor error•
Sub-cool Heat Ex. gas outlet temp. sensor error•
(8) (3)
Liquid pipe temp. sensor error
(8) (4)
Current sensor error
(8) (6)
Discharge pressure sensor error•
Suction pressure sensor error•
High pressure switch error•
(9) (4)
Trip detection
(9) (5)
Compressor rotor position detection error (permanent
s
(9) (7)
Outdoor unit fan motor error
(9) (9)
4-way valve error
(10) (1)
Discharge temp. error
( ) : Number of flashing
D
REMOTE CONTROL
r
or occurs, the following display will be shown.
w
ill appear in the set room temperature display.)
“
is displayed, immediately contact authorized
personnel.
n
it number
s
ually 0)
Error code
Ex. Error code display
L
E REMOTE CONTROL
Error code
Ex. Error code display
lty unit No.
m
ote controller address)
r
or occurs, the following display will be shown.
w
ill appear in the set room temperature display.)
“
is displayed, immediately contact authorized
personnel.
