Fujitsu AOU36RML1 - Outdoor Unit Components

OUTDOOR UNIT
PARTS
232009.02.03
1
6
8
2
4
7
5
3
1 Top Panel Sub Assy
2 Front Panel
3 Fan Guard
4 Grip Side
5 Service Panel Sub Assy
6 Right Panel
7 Valve Cover Sub Assy
8 Grip
9374417025
9374094066
9374330010
9374173013
9374415038
9374599066
9374827015
9374172016
-- Emblem
-- Protective Net
-- Drain Assy
-- Drain Cap
9351355005
9375381011
9303029015
313166024302
Ref. Description Part number
