Fujitsu AOU36RML1 Service Manual

OUTDOOR UNIT
15
17
16
11
12
13
14
242009.02.03
25
24
23
22
18
21
20
21
20
21
19
21
19
11 Motor Bracket Sub Assy
12 Propeller Fan Assy
13 Fan Motor
14 Condenser A Assy
15 Separate Wall Assy
16 Base Assy
17 Coil. Choke
-- Cap Foot
18 Valve Plate A Assy
19
20
3-Way Valve Assy (1/2")
21 2-Way Valve Assy
22 Coil (Expansion Valve)(A=Red)
23 Coil (Expansion Valve)(B=White)
24 Coil (Expansion Valve)(C=Green)
25 Coil (Expansion Valve)(D=Blue)
9374418091
9366378020
9602114016
9374433148
9375226015
9374166183
9900366018
9374345014
-- Accumulator Supporter 9375214012
9374628087
3-Way Valve Assy (3/8") 9375103019
9375104016
9375102012
9900057084
9900057053
9900057060
9900057077
