Fujitsu AOU9RLFC Design & Technical Manual

¢
Model: AUU12RLF
AFR CFM 359
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kBtu kW kBtu kW kBtu kW kBtu kW kBtu kW kBtu kW
15 11.11 8.65 0.33 12.56 9.79 0.34 13.24 10.31 0.34 14.19 11.06 0.34 15.15 11.81 0.35 15.61 12.17 0.35
23 10.88 8.46 0.38 12.31 9.56 0.39 12.97 10.08 0.39 13.90 10.80 0.40 14.85 11.54 0.40 15.30 11.89 0.40
32 10.66 8.46 0.42 12.05 9.57 0.43 12.70 10.08 0.43 13.61 10.81 0.43 14.54 11.54 0.44 14.99 11.90 0.44
41 10.44 7.62 0.44 11.80 8.61 0.45 12.43 9.08 0.45 13.32 9.73 0.46 14.23 10.39 0.46 14.67 10.71 0.47
50 10.21 7.21 0.44 11.54 8.15 0.45 12.16 8.59 0.45 13.03 9.21 0.46 13.93 9.84 0.47 14.36 10.14 0.47
59 9.99 7.05 0.45 11.29 7.97 0.46 11.89 8.40 0.47 12.74 9.00 0.47 13.62 9.62 0.48 14.04 9.92 0.48
67 11.26 8.29 0.72 12.73 8.29 0.73 13.41 9.14 0.74 14.36 9.59 0.75 15.35 9.83 0.75 15.83 10.92 0.76
77 10.68 8.15 0.81 12.08 8.15 0.82 12.73 9.01 0.83 13.65 9.45 0.84 14.57 9.66 0.85 15.01 10.75 0.85
87 10.13 7.88 0.90 11.43 7.88 0.92 12.04 8.70 0.93 12.90 9.11 0.94 13.82 9.35 0.95 14.23 10.37 0.95
95 9.42 7.57 0.91 10.65 7.57 0.92 11.19 8.36 0.93 12.01 8.77 0.94 12.83 8.97 0.95 13.24 9.96 0.96
104 7.98 6.99 0.77 9.04 6.99 0.79 9.52 7.71 0.79 10.20 8.12 0.80 10.92 8.29 0.81 11.26 9.21 0.81
115 7.37 6.55 0.78 8.33 6.55 0.79 8.80 7.23 0.80 9.42 7.57 0.80 10.07 7.75 0.81 10.37 8.63 0.82
AFR
m
3
/h
610
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.2 19.4 21.7 22.8
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW
-10.0 3.26 2.54 0.33 3.68 2.87 0.34 3.88 3.02 0.34 4.16 3.24 0.34 4.44 3.46 0.35 4.58 3.57 0.35
-5.0 3.19 2.48 0.38 3.61 2.80 0.39 3.80 2.95 0.39 4.07 3.17 0.40 4.35 3.38 0.40 4.48 3.48 0.40
0.0 3.12 2.48 0.42 3.53 2.80 0.43 3.72 2.95 0.43 3.99 3.17 0.43 4.26 3.38 0.44 4.39 3.49 0.44
5.0 3.06 2.23 0.44 3.46 2.52 0.45 3.64 2.66 0.45 3.90 2.85 0.46 4.17 3.05 0.46 4.30 3.14 0.47
10.0 2.99 2.11 0.44 3.38 2.39 0.45 3.56 2.52 0.45 3.82 2.70 0.46 4.08 2.88 0.47 4.21 2.97 0.47
15.0 2.93 2.07 0.45 3.31 2.34 0.46 3.49 2.46 0.47 3.73 2.64 0.47 3.99 2.82 0.48 4.12 2.91 0.48
19.4 3.30 2.43 0.72 3.73 2.43 0.73 3.93 2.68 0.74 4.21 2.81 0.75 4.50 2.88 0.75 4.64 3.20 0.76
25.0 3.13 2.39 0.81 3.54 2.39 0.82 3.73 2.64 0.83 4.00 2.77 0.84 4.27 2.83 0.85 4.40 3.15 0.85
30.6 2.97 2.31 0.90 3.35 2.31 0.92 3.53 2.55 0.93 3.78 2.67 0.94 4.05 2.74 0.95 4.17 3.04 0.95
35.0 2.76 2.22 0.91 3.12 2.22 0.92 3.28 2.45 0.93 3.52 2.57 0.94 3.76 2.63 0.95 3.88 2.92 0.96
40.0 2.34 2.05 0.77 2.65 2.05 0.79 2.79 2.26 0.79 2.99 2.38 0.80 3.20 2.43 0.81 3.30 2.70 0.81
46.0 2.16 1.92 0.78 2.44 1.92 0.79 2.58 2.12 0.80 2.76 2.22 0.80 2.95 2.27 0.81 3.04 2.53 0.82
- 9 -
4-1. Cooling capacity 4. Capacity table
CASSETTE TYPE AUU09-18RLF CASSETTE TYPE AUU09-18RLF

Fujitsu AOU9RLFC Specifications
