Fujitsu AOU9RLFC Design & Technical Manual

4-2. Heating capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: AUU9RLF
AFR CFM 318
Indoor temperature
°FDB 60 65 70 75
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
-5 -7 14.7 1.84 14.3 1.88 14.0 1.92 13.3 1.99
5 3 16.1 1.79 15.7 1.83 15.4 1.87 14.6 1.94
14 12 16.8 1.73 16.4 1.76 16.0 1.80 15.2 1.87
23 19 17.3 1.67 16.9 1.70 16.5 1.74 15.7 1.81
32 28 17.4 1.61 17.0 1.64 16.6 1.68 15.7 1.74
41 37 17.4 1.67 17.0 1.71 16.6 1.74 15.8 1.81
47 43 18.9 1.73 18.5 1.76 18.0 1.80 17.1 1.87
50 47 20.9 1.75 20.4 1.79 19.9 1.83 18.9 1.90
59 50 21.6 1.76 21.1 1.80 20.6 1.84 19.6 1.91
AFR
m
3
/h
540
Indoor temperature
°CDB 15.6 18.3 21.1 23.9
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP
kW kW kW kW
-20.6 -21.7 4.31 1.84 4.20 1.88 4.10 1.92 3.90 1.99
-15.0 -16.1 4.73 1.79 4.61 1.83 4.50 1.87 4.28 1.94
-10.0 -11.1 4.91 1.73 4.80 1.76 4.68 1.80 4.45 1.87
-5.0 -7.2 5.08 1.67 4.96 1.70 4.84 1.74 4.59 1.81
0.0 -2.2 5.10 1.61 4.98 1.64 4.86 1.68 4.61 1.74
5.0 2.8 5.11 1.67 4.99 1.71 4.87 1.74 4.62 1.81
8.3 6.1 5.54 1.73 5.41 1.76 5.28 1.80 5.01 1.87
10.0 8.3 6.12 1.75 5.98 1.79 5.83 1.83 5.54 1.90
15.0 10.0 6.34 1.76 6.19 1.80 6.04 1.84 5.74 1.91
¢
Model: AUU12RLF
AFR CFM 359
Indoor temperature
°FDB 60 65 70 75
Outdoor temperature
°FDB °FWB
TC IP TC IP TC IP TC IP
kBtu/h kW kBtu/h kW kBtu/h kW kBtu/h kW
-5 -7 15.8 2.23 15.4 2.27 15.0 2.32 14.3 2.36
5 3 17.6 2.16 17.2 2.21 16.8 2.25 15.9 2.34
14 12 18.3 2.09 17.8 2.13 17.4 2.17 16.5 2.26
23 19 19.2 2.01 18.7 2.05 18.2 2.10 17.3 2.18
32 28 19.5 1.95 19.0 1.99 18.5 2.03 17.6 2.11
41 37 19.7 1.86 19.2 1.90 18.8 1.94 17.8 2.02
47 43 20.4 1.92 19.9 1.96 19.4 2.00 18.4 2.08
50 47 22.5 1.94 22.0 1.98 21.4 2.02 20.4 2.10
59 50 23.3 1.95 22.8 1.99 22.2 2.03 21.1 2.11
AFR
m
3
/h
610
Indoor temperature
°CDB 15.6 18.3 21.1 23.9
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP
kW kW kW kW
-20.6 -21.7 4.63 2.23 4.52 2.27 4.41 2.32 4.19 2.36
-15.0 -16.1 5.16 2.16 5.03 2.21 4.91 2.25 4.66 2.34
-10.0 -11.1 5.36 2.09 5.23 2.13 5.10 2.17 4.85 2.26
-5.0 -7.2 5.61 2.01 5.48 2.05 5.35 2.10 5.08 2.18
0.0 -2.2 5.70 1.95 5.57 1.99 5.43 2.03 5.16 2.11
5.0 2.8 5.78 1.86 5.64 1.90 5.50 1.94 5.23 2.02
8.3 6.1 5.99 1.92 5.84 1.96 5.70 2.00 5.42 2.08
10.0 8.3 6.60 1.94 6.44 1.98 6.28 2.02 5.97 2.10
15.0 10.0 6.84 1.95 6.67 1.99 6.51 2.03 6.19 2.11
- 11 -
4-2. Heating capacity 4. Capacity table
CASSETTE TYPE AUU09-18RLF CASSETTE TYPE AUU09-18RLF
