Fujitsu AOU9RLFC Design & Technical Manual

1. Specifications
Type
Cassette
Inverter heat pump
Model name AUU9RLF AUU12RLF AUU18RLF
Power supply 208/230 V ~ 60 Hz
Available voltage range 187—253 V
Capacity
Cooling
Rated
kW 2.64 3.52 5.28
Btu/h 9,000 12,000 18,000
Min.—Max.
kW 0.90—3.60 0.90—4.00 0.90—5.90
Btu/h 3,100—12,000 3,100—13,600 3,100—20,100
Heating
Rated
kW 3.52 4.69 6.33
Btu/h 12,000 16,000 21,600
Min.—Max.
kW 0.90—5.28 0.90—5.70 0.90—7.50
Btu/h 3,100—18,000 3,100—19,400 3,100—25,600
Input power
Cooling
Rated
kW
0.62 0.94 1.61
Min.—Max. 1.40 1.45 2.15
Heating
Rated 0.89 1.44 1.76
Min.—Max. 1.80 2.00 2.60
Current
Cooling
Rated A
3.0 4.4 7.1
Heating 4.1 6.7 7.7
EER Cooling
kW/kW 4.25 3.74 3.28
Btu/h 14.5 12.8 11.2
COP Heating
kW/kW 3.95 3.25 3.59
Btu/h 13.5 11.1 12.3
SEER Cooling Btu/h 24.0 21.9 20.1
HSPF Heating Btu/h 13.0 12.2 11.5
Power factor
Cooling
%
90 94 98
Heating 94 94 99
Moisture removal pints/h (L/h) 1.3 (0.6) 2.5 (1.2) 4.6 (2.2)
Maximum operating current *
1
Cooling
A
9.3 9.4 10.0
Heating 10.8 10.9 14.0
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
318 (540) 359 (610) 400 (680)
MED 288 (490) 312 (530) 341 (580)
LOW 259 (440) 277 (470) 288(490)
QUIET 230 (390) 241 (410) 241 (410)
Heating
HIGH 318 (540) 359 (610) 471 (800)
MED 288 (490) 312 (530) 400 (680)
LOW 259 (440) 277 (470) 341 (580)
QUIET 230 (390) 241 (410) 265 (450)
Type × Q'ty Turbo fan × 1
Motor output W 54
Sound pressure level *
2
Cooling
HIGH
dB (A)
33 37 40
MED 32 33 36
LOW 29 31 32
QUIET 28 28 28
Heating
HIGH 34 37 44
MED 32 33 40
LOW 29 31 36
QUIET 27 28 30
Heat exchanger type
Dimensions (H × W × D) in (mm)
8-1/4 × 51-9/16 × 1/2 + 8-1/4 × 49-3/16 × 1/2
(210 × 1,310 × 13.3 + 210 × 1,250 × 13.3)
Fin pitch FPI 21
Rows × Stages 2 × 10
Pipe type Copper tube
Fin type Aluminum
Dimensions
(H × W × D)
Net
in (mm)
9-5/8 × 22-7/16 × 22-7/16 (245 × 570 × 570)
Gross 10-7/16 × 28-3/4 × 24-5/8 (265 × 730 × 625)
Weight
Net
lb (kg)
33 (15)
Gross 40 (18)
Connection pipe
Size
Liquid
in (mm)
Ø1/4 (Ø6.35)
Gas Ø3/8 (Ø9.52) Ø1/2 (Ø12.70)
Method Flare
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 60 to 86 (16 to 30)
Drain hose
Material Hard PVC
Size in (mm) Ø 3/4(I.D.), Ø 1-1/16(O.D.) (Ø 20.7 [I.D.], Ø 26.6 [O.D.])
Remote controller type Wired (Wireless [option])
Cassette grille
(Standard type: Option)
Model name
UTG-CCGF
Material PS
Color
White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
in (mm)
1-15/16 × 27-9/16 × 27-9/16 (49 × 700 × 700)
Gross 4-3/4 × 30-1/8 × 29-3/4 (120 × 765 × 755)
Weight
Net
lb (kg)
5.7 (2.6)
Gross 10 (4.5)
Cassette grille
(Grid type: Option)
Model name
UTG-CCGFG
Material PS
Color
White
Approximate color of Munsell 9PB 9.1/0.2
Dimensions
(H × W × D)
Net
in (mm)
1-15/16 × 24-7/16 × 24-7/16 (49 × 620 × 620)
Gross 4-3/4 × 30-1/8 × 29-3/4 (120 × 765 × 755)
Weight
Net
lb (kg)
5.1 (2.3)
Gross 10 (4.5)
- 2 -
1. Specifications
CASSETTE TYPE AUU09-18RLF CASSETTE TYPE AUU09-18RLF

Fujitsu AOU9RLFC Specifications
