FLOOR TYPE AGU9-15RLF FLOOR TYPE AGU9-15RLF
CAPACITY TABLE6.
COOLING CAPACITY6-1.
MODEL

: AGU9RLF
AFR 336
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
15 7.84 6.74 0.20 8.86 6.73 0.21 9.34 7.43 0.21 10.00 7.79 0.21 10.69 7.98 0.21 11.02 8.86 0.21
23 7.52 6.44 0.22 8.50 6.44 0.23 8.96 7.10 0.23 9.59 7.45 0.23 10.25 7.62 0.24 10.57 8.47 0.24
32 7.11 6.23 0.22 8.04 6.22 0.23 8.47 6.86 0.23 9.07 7.20 0.23 9.70 7.37 0.24 9.99 8.19 0.24
41 6.89 6.07 0.23 7.79 6.06 0.24 8.21 6.68 0.24 8.79 7.01 0.24 9.40 7.17 0.25 9.69 7.97 0.25
50 6.87 6.04 0.22 7.76 6.03 0.23 8.18 6.65 0.23 8.76 6.98 0.23 9.36 7.14 0.24 9.65 7.94 0.24
59 6.11 5.44 0.24 6.90 5.44 0.25 7.27 6.00 0.25 7.79 6.29 0.25 8.33 6.44 0.26 8.58 7.15 0.26
67 6.88 6.10 0.26 7.77 6.09 0.27 8.20 6.72 0.27 8.78 7.05 0.27 9.38 7.21 0.28 9.67 8.02 0.28
77 7.79 6.88 0.44 8.80 6.87 0.45 9.28 7.58 0.45 9.93 7.95 0.45 10.62 8.14 0.46 10.95 9.04 0.46
87 7.36 6.49 0.49 8.32 6.48 0.50 8.77 7.15 0.51 9.39 7.50 0.51 10.04 7.67 0.52 10.35 8.53 0.52
95 7.06 6.23 0.54 7.97 6.22 0.55 8.41 6.86 0.55 9.00 7.20 0.56 9.62 7.37 0.57 9.92 8.19 0.57
104 6.54 5.77 0.56 7.39 5.76 0.57 7.79 6.35 0.57 8.34 6.67 0.58 8.92 6.82 0.59 9.19 7.58 0.59
115 6.43 5.69 0.57 7.27 5.68 0.58 7.66 6.26 0.59 8.20 6.57 0.59 8.77 6.73 0.60 9.04 7.48 0.60
AFR : Air Flow Rate (CFM)
TC : Total Capacity (kBtu/h)
SHC : Sensible Heat Capacity (kBtu/h)
IP : Input Power (kW)
AFR 9.5
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.7 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10.0 2.30 1.98 0.20 2.60 1.97 0.21 2.74 2.18 0.21 2.93 2.28 0.21 3.13 2.34 0.21 3.23 2.60 0.21
-5.0 2.20 1.89 0.22 2.49 1.89 0.23 2.62 2.08 0.23 2.81 2.18 0.23 3.00 2.23 0.24 3.10 2.48 0.24
0.0 2.08 1.83 0.22 2.36 1.82 0.23 2.48 2.01 0.23 2.66 2.11 0.23 2.84 2.16 0.24 2.93 2.40 0.24
5.0 2.02 1.78 0.23 2.28 1.78 0.24 2.41 1.96 0.24 2.58 2.06 0.24 2.75 2.10 0.25 2.84 2.34 0.25
10.0 2.01 1.77 0.22 2.27 1.77 0.23 2.40 1.95 0.23 2.57 2.05 0.23 2.74 2.09 0.24 2.83 2.33 0.24
15.0 1.79 1.60 0.24 2.02 1.59 0.25 2.13 1.76 0.25 2.28 1.84 0.25 2.44 1.89 0.26 2.52 2.10 0.26
19.4 2.02 1.79 0.26 2.28 1.79 0.27 2.40 1.97 0.27 2.57 2.07 0.27 2.75 2.11 0.28 2.83 2.35 0.28
25.0 2.28 2.02 0.44 2.58 2.01 0.45 2.72 2.22 0.45 2.91 2.33 0.45 3.11 2.38 0.46 3.21 2.65 0.46
30.6 2.16 1.90 0.49 2.44 1.90 0.50 2.57 2.09 0.51 2.75 2.20 0.51 2.94 2.25 0.52 3.03 2.50 0.52
35.0 2.07 1.83 0.54 2.34 1.82 0.55 2.46 2.01 0.55 2.64 2.11 0.56 2.82 2.16 0.57 2.91 2.40 0.57
40.0 1.92 1.69 0.56 2.17 1.69 0.57 2.28 1.86 0.57 2.44 1.95 0.58 2.61 2.00 0.59 2.69 2.22 0.59
46.0 1.89 1.67 0.57 2.13 1.66 0.58 2.25 1.84 0.59 2.40 1.93 0.59 2.57 1.97 0.60 2.65 2.19 0.60
AFR : Air Flow Rate (m
3
/min)
TC : Total Capacity (kW)
SHC : Sensible Heat Capacity (kW)
IP : Input Power (kW)
