Fujitsu AOU9RLFF User Manual

- (02 - 07) -
OUTDOOR UNIT AOU9-15RLFF OUTDOOR UNIT AOU9-15RLFF
CAPACITY COMPENSATION RATE FOR PIPE LENGTH 5.
AND HEIGHT DIFFERENCE
MODEL

: AOU9RLFF, AOU12RLFF
Height difference H

1 Indoor unit is higher than outdoor unit.

2 Indoor unit is lower than outdoor unit.
Indoor unit
Indoor unit
Connection pipe
Outdoor unit
Outdoor unit
Connection pipe
HEATING
Pipe length (m)
5m 7.5m 10m 15m 20m
17ft. 25ft. 33ft. 50ft. 67ft.
Height
difference H
Û
1
Indoor unit is
higher than
outdoor unit.
15m 50ft. - - - 0.956 0.938
10m 33ft. - - 1.004 0.956 0.938
7.5m 25ft. - 1.013 1.004 0.956 0.938
5m 17ft. 1.000 1.013 1.004 0.956 0.938
0m 0ft. 1.000 1.013 1.004 0.956 0.938
Û
2
Indoor unit is
lower than
outdoor unit
-5m -17ft. 0.995 1.008 0.999 0.951 0.933
-7. 5 m -25ft. - 1.005 0.997 0.948 0.931
-10m -33ft. - - 0.994 0.946 0.929
-15m -50ft. - - - 0.937 0.919
COOLING
Pipe length (m)
5m 7.5m 10m 15m 20m
17ft. 25ft. 33ft. 50ft. 67ft.
Height
difference H
Û
1
Indoor unit is
higher than
outdoor unit.
15m 50ft. - - - 0.893 0.909
10m 33ft. - - 0.955 0.908 0.924
7.5m 25ft. - 0.975 0.959 0.912 0.928
5m 17ft. 0.992 0.979 0.963 0.916 0.931
0m 0ft. 1.000 0.987 0.970 0.923 0.939
Û
2
Indoor unit is
lower than
outdoor unit
-5m -17ft. 1.000 0.987 0.970 0.923 0.939
-7. 5 m -25ft. - 0.987 0.970 0.923 0.939
-10m -33ft. - - 0.970 0.923 0.939
-15m -50ft. - - - 0.923 0.939
H
H
