Fujitsu AOU9RLFF User Manual

- (01 - 11) -
FLOOR TYPE AGU9-15RLF FLOOR TYPE AGU9-15RLF
MODEL

: AGU15RLF
AFR 383
Indoor temperature
°FDB 64 70 75 80 85 90
°FWB 54 60 63 67 71 73
Outdoor temperature
°FDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
15 12.17 9.38 0.40 13.75 9.37 0.41 14.49 10.33 0.41 15.52 10.84 0.42 16.59 11.09 0.42 17.10 12.33 0.42
23 11.85 9.06 0.43 13.39 9.05 0.44 14.12 9.98 0.44 15.11 10.47 0.45 16.16 10.71 0.45 16.65 11.91 0.45
32 11.53 8.77 0.44 13.03 8.75 0.45 13.74 9.66 0.45 14.71 10.13 0.46 15.72 10.37 0.46 16.21 11.52 0.46
41 11.40 8.71 0.45 12.88 8.70 0.46 13.58 9.59 0.46 14.54 10.07 0.47 15.54 10.30 0.47 16.02 11.45 0.47
50 11.37 8.68 0.47 12.85 8.67 0.48 13.55 9.56 0.48 14.50 10.03 0.49 15.51 10.26 0.49 15.98 11.41 0.49
59 10.71 8.62 0.48 12.10 8.61 0.49 12.76 9.50 0.49 13.66 9.97 0.50 14.60 10.20 0.50 15.05 11.33 0.50
67 11.59 9.12 0.61 13.10 9.11 0.62 13.81 10.05 0.62 14.79 10.54 0.63 15.81 10.78 0.64 16.29 11.99 0.64
77 12.30 9.64 0.90 13.90 9.63 0.91 14.65 10.62 0.92 15.69 11.14 0.93 16.77 11.40 0.94 17.29 12.67 0.95
87 11.63 9.11 1.00 13.14 9.10 1.02 13.85 10.04 1.03 14.83 10.53 1.04 15.85 10.78 1.05 16.34 11.98 1.06
95 11.13 8.74 1.09 12.58 8.73 1.11 13.26 9.62 1.12 14.20 10.10 1.13 15.18 10.33 1.14 15.65 11.48 1.15
104 9.89 7.75 1.14 11.17 7.74 1.16 11.78 8.53 1.17 12.61 8.96 1.18 13.48 9.16 1.19 13.90 10.18 1.20
115 9.33 7.31 1.15 10.54 7.30 1.17 11.12 8.05 1.18 11.90 8.45 1.19 12.72 8.65 1.20 13.11 9.61 1.21
AFR : Air Flow Rate (CFM)
TC : Total Capacity (kBtu/h)
SHC : Sensible Heat Capacity (kBtu/h)
IP : Input Power (kW)
AFR 10.8
Indoor temperature
°CDB 17.8 21.1 23.9 26.7 29.4 32.2
°CWB 12.2 15.6 17.7 19.4 21.7 22.8
Outdoor temperature
°CDB TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
-10.0 3.57 2.75 0.40 4.03 2.74 0.41 4.25 3.03 0.41 4.55 3.18 0.42 4.86 3.25 0.42 5.01 3.61 0.42
-5.0 3.47 2.65 0.43 3.92 2.65 0.44 4.14 2.92 0.44 4.43 3.07 0.45 4.73 3.14 0.45 4.88 3.49 0.45
0.0 3.38 2.57 0.44 3.82 2.57 0.45 4.03 2.83 0.45 4.31 2.97 0.46 4.61 3.04 0.46 4.75 3.38 0.46
5.0 3.34 2.55 0.45 3.78 2.55 0.46 3.98 2.81 0.46 4.26 2.95 0.47 4.55 3.02 0.47 4.70 3.35 0.47
10.0 3.33 2.54 0.47 3.77 2.54 0.48 3.97 2.80 0.48 4.25 2.94 0.49 4.54 3.01 0.49 4.68 3.34 0.49
15.0 3.14 2.53 0.48 3.55 2.52 0.49 3.74 2.78 0.49 4.00 2.92 0.50 4.28 2.99 0.50 4.41 3.32 0.50
19.4 3.40 2.67 0.61 3.84 2.67 0.62 4.05 2.94 0.62 4.33 3.09 0.63 4.63 3.16 0.64 4.78 3.51 0.64
25.0 3.60 2.83 0.90 4.07 2.82 0.91 4.29 3.11 0.92 4.60 3.27 0.93 4.92 3.34 0.94 5.07 3.71 0.95
30.6 3.41 2.67 1.00 3.85 2.67 1.02 4.06 2.94 1.03 4.35 3.09 1.04 4.65 3.16 1.05 4.79 3.51 1.06
35.0 3.26 2.56 1.09 3.69 2.56 1.11 3.89 2.82 1.12 4.16 2.96 1.13 4.45 3.03 1.14 4.59 3.37 1.15
40.0 2.90 2.27 1.14 3.27 2.27 1.16 3.45 2.50 1.17 3.70 2.62 1.18 3.95 2.69 1.19 4.07 2.98 1.20
46.0 2.73 2.14 1.15 3.09 2.14 1.17 3.26 2.36 1.18 3.49 2.48 1.19 3.73 2.53 1.20 3.84 2.82 1.21
AFR : Air Flow Rate (m
3
/min)
TC : Total Capacity (kW)
SHC : Sensible Heat Capacity (kW)
IP : Input Power (kW)
