Item no. Part no. Part name Service part
50 9387587012 Base assy ♦
51 9383765032 WLAN adapter holder assy ♦
52
9711141422 Main PCB (For 09 model) ♦
9711141439 Main PCB (For 12 model) ♦
53 9387488043 Cable guide ♦
54 9711146076 Display assy ♦
55 9711147011 Indicator PCB ♦
56 9306489045 Terminal ♦
57 9603821012 Brushless motor ♦
58 9387589030 Motor case assy ♦
59 9317250009 Air clean filter assy ♦
60 9332911008 Electric filter holder ♦
61 9387593228 Evaporator total assy ♦
62 9900627041 Thermistor assy ♦
63 9387467000 Room thermistor holder ♦
64 9333628004 Bearing D assy ♦
65 9387055016 Crossflow fan assy ♦
a — Box shield —
b — Control box —
c — PCB holder A —
d — Control cover —
e — Display case assy —
f — Motor case —
g — Motor cover
2-1. Models: ASUG09LMAS and ASUG12LMAS - (02-5) - 2. Indoor unit parts list
