Fujitsu AOUG48LMAS1 User Manual

Item
no.
Part name
Part no.
AMUG24LMAS AMUG30LMAS AMUG36LMAS AMUG48LMAS
Panel, Sheet metal, Miscellaneous
1 Cabinet AE-100682-02 AE-100682-02 AE-100682-06 AE-100682-06
Insulation - Cabinet 68-101121-02 68-101121-02 68-101121-15 68-101121-15
Insulation Retainer Rod (2) 45-102868-03 45-102868-03 45-102868-03 45-102868-03
2 Coil Door AE-100685-23 AE-100685-23 N/A N/A
Insulation - Coil Door 68-101577-07 68-101577-07 68-101577-10 68-101577-10
3 Top Cover Plate AE-100686-02 AE-100686-02 AE-100686-02 AE-100686-02
Insulation - Top Cover Plate 68-101122-02 68-101122-02 68-101122-02 68-101122-02
4 Blower Door AE-100684-22 AE-100684-22 AE-100684-22 AE-100684-22
Insulation - Blower Door 68-101576-02 68-101576-02 68-101576-02 68-101576-02
5 Access Panel AE-101133-21 AE-101133-21 AE-101133-21 AE-101133-21
Insulation - Access Panel 68-101644-01 68-101644-01 68-101644-01 68-101644-01
6 Drain Pan - Vertical See RCH Coil Parts List
7 Drain Pan - Horizontal See RCH Coil Parts List
8 Plate - Block Off AE-100455-01 AE-100455-01 AE-100455-01 AE-100455-01
9 Cabinet Brace AE-101134-03 AE-101134-03 AE-101134-03 AE-101134-03
10 Middle Brace AE-101054-02 AE-101054-02 AE-101054-02 AE-101054-02
13a Heat Barrier AE-100683-05 AE-100683-05 AE-100683-06 AE-100683-06
13b Heat Barrier Side (2) AE-104241-01 AE-104241-01 AE-104241-01 AE-104241-01
Touch-up Paint - Private
Label Gray (Aerosol)
523014 523014 523014 523014
Touch-up Paint - Private
Label Gray (Paint Pens)
523015 523015 523015 523015
Coil group
12 Replacement Coil w/TXV
RCH-3021SNAV
UA
RCH-3021SNAV
UA
RCH-4821SNAV
UA
RCH-4821SNAV
UA
Horizontal Adapter Kit See specified RCH Coil Parts List
Drain Pan - Vertical See specified RCH Coil Parts List
TXV See specified RCH Coil Parts List
Heater kits
Heater Kit - 3kW/208-240/1 RXBH-1724A03J RXBH-1724A03J RXBH-1724A03J N/A
Heater Kit - 5kW/208-240/1
RXBH-1724A05J
RXBH-1724B05J
RXBH-1724C05J
RXBH-1724A05J
RXBH-1724B05J
RXBH-1724C05J
RXBH-1724A05J
RXBH-1724B05J
RXBH-1724C05J
RXBH-1724A05J
RXBH-1724B05J
RXBH-1724C05J
Heater Kit - 7kW/208-240/1
RXBH-1724A07J
RXBH-1724B07J
RXBH-1724C07J
RXBH-1724A07J
RXBH-1724B07J
RXBH-1724C07J
RXBH-1724A07J
RXBH-1724B07J
RXBH-1724C07J
RXBH-1724A07J
RXBH-1724B07J
RXBH-1724C07J
Heater Kit - 10kW/208-240/1
RXBH-1724A10J
RXBH-1724B10J
RXBH-1724C10J
RXBH-1724A10J
RXBH-1724B10J
RXBH-1724C10J
RXBH-1724A10J
RXBH-1724B10J
RXBH-1724C10J
RXBH-1724A10J
RXBH-1724B10J
RXBH-1724C10J
Heater Kit - 15kW/208-240/1 N/A N/A RXBH-1724A15J RXBH-1724A15J
Heater Kit - 18kW/208-240/1 N/A N/A N/A RXBH-1724A18J
Heater Kit - 20kW/208-240/1 N/A N/A N/A RXBH-24A20J
Heater Kit - 25kW/208-240/1 N/A N/A N/A N/A
Heater Kit - 30kW/208-240/1 N/A N/A N/A N/A
2-1. Models: AMUG24LMAS, AMUG30LMAS, AMUG36LMAS, and AMUG48LMAS - (02-3) - 2. Indoor unit parts list
TECHNICAL DATA AND PARTS LIST TECHNICAL DATA AND PARTS LIST
