Item
no.
Part name
Part no.
AMUG24LMAS AMUG30LMAS AMUG36LMAS AMUG48LMAS
Electrical group
17 Transformer* 46-101905-01 46-101905-01 46-101905-01 46-101905-01
18 Control Board* 47-107563-01 47-107563-02 47-107563-03 47-107563-04
Wiring Harness - TB1 to
Ground.
45-107910-01 45-107910-01 45-107910-01 45-107910-01
Wiring Harness - TB1 to
Power (ACIN)
45-107910-03 45-107910-03 45-107910-03 45-107910-03
Wiring Harness - TB2 to
Remote Control
45-107910-02 45-107910-02 45-107910-02 45-107910-02
Wiring Harness - TB2 to
External Input
45-107910-04 45-107910-04 45-107910-04 45-107910-04
11 Terminal Block 1 N/A N/A 45-107911-01 45-107911-01
11 Terminal Block 2 N/A N/A 45-107911-02 45-107911-02
Coil Sensor 47-107921-01 47-107921-01 47-107921-01 47-107921-01
Return Air Thermistor 47-107921-02 N/A 47-107921-02 47-107921-02
Communication PCB 9710019005
Terminal (4P) 9306488154
Terminal (5P) 9900896027
Thermistor (Pipe) 9901058004
Thermistor (Room) 9900960056
Blower group
15
Blower Assembly*
(Includes items 16-22)
AS-101885-42 AS-101885-40 AS-101885-41 AS-101885-39
16
Mounting Bracket - Control
Board
10-101049-03 10-101049-03 10-101049-03 10-101049-03
17 Transformer See Electrical group
18 Control Board See Electrical group
Control Identity EEPROM See Electrical group
19 Blower Housing w/Wheel 70-101729-02 70-101729-02 70-101729-08 70-101729-08
Blower Wheel* 703014 703014 703023 703023
20 Motor Mount - Band 70-19927-04 70-19927-04 70-19927-04 70-19927-04
21 Motor Mount - Arm (4) 70-19929-10 70-19929-10 70-19929-10 70-19929-10
22 Blower Motor* 51-102601-01 51-102601-01 51-102603-01 51-102603-01
23 Mounting Bracket Cover 10-101797-03 10-101797-03 10-101797-03 10-101797-03
*: It is recommended that stock be maintained for this part.
2-1. Models: AMUG24LMAS, AMUG30LMAS, AMUG36LMAS, and AMUG48LMAS
- (02-5) - 2. Indoor unit parts list
