Item
no.
Part name
Part no.
AMUG24LMAS AMUG30LMAS AMUG36LMAS AMUG48LMAS
1 Drain Pan - Vertical* 68-104822-03
2 Distributor Assembly* 83-104030-02
Horizontal Adapter Kit -
Includes Straps, Shields,
Drain Pan and Insulation
RXHH-A03
3 Drain Pan - Horizontal AE-101128-31
Insulation - Horizontal Pan 68-100528-01
4 Rear/Front Shield (2) AE-101136-07
5 Straps (2) AE-100530-07
*: It is recommended that stock be maintained for this part.
2-1. Models: AMUG24LMAS, AMUG30LMAS, AMUG36LMAS, and AMUG48LMAS - (02-7) - 2. Indoor unit parts list
