Item no. Part no. Part name Service part
1 9374417070 Top panel sub assy ♦
2 9375361013 Net rubber ♦
3 9375381011 Protective net ♦
4 9374420308 Condenser A sub assy ♦
5 9375211011 Thermo sensor holder ♦
6 9374166206 Base assy ♦
7 9374416271 Right panel sub assy ♦
8 9374174010 Valve cover ♦
9 313166024302 Drain cap ♦
10 9303029015 Drain assy ♦
11 9374415106 Service panel sub assy ♦
12 9351355005 Rear emblem ♦
13 9375212018 Label (Halcyon) ♦
14 9374414079 Front panel sub assy ♦
15 9374330010 Fan guard ♦
16 9366378020 Propeller fan assy ♦
17 9603777012 Fan motor assy ♦
18 9374418152 Motor bracket sub assy ♦
a — Separation wall —
b — Accumulator support assy —
3-1. Models: AOU24RGLX and AOU30RGLX - (02-9) - 3. Outdoor unit parts list
