Item no. Part no. Part name Service part
50 9378530010 Heat sink ♦
51 9900223014 Choke coil ♦
52 9707592016 ACTPM ♦
53 9708512181 Transistor PCB ♦
54 9900514013 Thermistor (Heat exchanger) ♦
55 9900463007 Thermistor (Outdoor temp.) ♦
56 9900827021 Thermistor (Compressor temp.) ♦
57 9901041020 Thermistor (Discharge temp.) ♦
58 9900203023 Terminal (5P) ♦
59 9709894040 Filter PCB ♦
60
9711685001 Main PCB (24 model) ♦
9711685018 Main PCB (30 model) ♦
61 9708513072 Capacitor PCB ♦
62 9704265012 Thermistor ♦
— 9707837032 Wire assy ♦
— 9367595112 Wire (Pressure switch) (Red) ♦
— 9708548012
Wire with connector (White)
(CN40 on Main PCB—CN301 on Transistor PCB)
♦
— 9708550015
Wire with connector (White)
(CN42 on Main PCB—CN303 on Transistor PCB)
♦
— 9708549019
Wire with connector (Red)
(CN400 on Main PCB—ACTPM)
♦
a — Heat sink cover —
b — Case (Inverter and Heat sink) —
c — RFM A —
d — Case (PCB) —
e — Case (Condenser) —
3-1. Models: AOU24RGLX and AOU30RGLX - (02-11) - 3. Outdoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
