Item no. Part no. Part name Service part
100 9374426133 Accumulator sub assy ♦
101 9378851177 Compressor cover A ♦
102 9378851184 Compressor cover D ♦
103 9378851283 Compressor cover B ♦
104 9378851023 Compressor cover C ♦
105 9970095030 Expansion valve coil ♦
106 9370947144 Expansion valve assy ♦
107 9377958013 3-way valve assy ♦
108 9374470044 3-way valve sub assy ♦
109 9354022010 Accumulator holder rubber ♦
110 9970055034 Solenoid ♦
111 9810135001 Compressor ♦
112 9374425198 4-way valve assy ♦
113 9900186012 Pressure switch ♦
a — Cover plate —
b — Valve plate —
3-1. Models: AOU24RGLX and AOU30RGLX - (02-13) - 3. Outdoor unit parts list
