Item no. Part no. Part name Service part
50 9900592011 Choke coil ♦
51 9708590004 ACTPM ♦
52 9708497242 Inverter PCB ♦
53 9900922016 Thermistor assy ♦
54 9900565046 Thermistor (Outdoor temp.) ♦
55 9900923013 Thermistor (Heat exchanger) ♦
56 9900428167 Terminal ♦
57 9380495000 Control box cover ♦
58
9710455162 Main PCB (36 model) ♦
9710455148 Main PCB (48 model) ♦
59 9709911181 Filter PCB ♦
60 9380483007 Heat sink A ♦
61 9380980001 Heat sink B ♦
— 9710456008
Wire with connector (Black)
(CN251 on Main PCB—CN380 on Inverter PCB)
♦
— 9708609010
Wire with connector (White)
(CN271 on Main PCB—CN390 on Inverter PCB)
♦
— 9708610016
Wire with connector (White)
(CN281 on Main PCB—CN320 on Inverter PCB)
♦
— 9708612010
Wire with connector (Black)
(CN395 on Inverter PCB—CN11 on ACTPM)
♦
— 9708613017
Wire with connector (Blue)
(CN370 on Inverter PCB—CN501 on Filter PCB)
♦
a — Duct D —
b — Control box bracket B —
c — Control box (Inverter) —
d — Control box (Main) assy —
3-2. Models: AOUG36LMAS1 and AOUG48LMAS1 - (02-17) - 3. Outdoor unit parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
