Fujitsu AOUH12LMAH1 User Manual

1. Specifications
Type
Wall mounted
Inverter heat pump
Model name ASUH09LMAS ASUH12LMAS
Power supply 208/230 V ~ 60 Hz
Power supply intake Outdoor unit
Available voltage range 187—253 V
Capacity
Cooling
Rated
kW 2.64 3.52
Btu/h 9,000 12,000
Min.—Max.
kW 1.0—3.37 1.0—3.90
Btu/h 3,400—11,500 3,400—13,300
Heating
Rated
kW 3.52 4.69
Btu/h 12,000 16,000
Min.—Max.
kW 0.82—4.69 0.82—5.60
Btu/h 2,800—16,000 2,800—19,100
Heating
(17 °F)
*1
Rated
kW 2.17 3.02
Btu/h 7,400 10,300
Max.
kW 3.09 3.72
Btu/h 10,550 12,700
Input power
Cooling
Rated
kW
0.585 0.960
Min.—Max. 0.14—1.27 0.14—1.27
Heating
Rated 0.79 1.28
Min.—Max. 0.14—1.67 0.14—1.67
Heating
(17 °F)
*1
Rated 0.68 1.04
Max. 1.39 1.39
Current
Cooling
Rated A
3.0 4.7
Heating 3.9 6.0
EER Cooling
kW/kW 4.51 3.66
Btu/hW 15.4 12.5
COP Heating
kW/kW 4.45 3.66
Btu/hW 15.2 12.5
SEER Cooling Btu/hW 26.5 23.0
HSPF Heating Btu/hW 13.0 12.5
Power factor
Cooling
%
84.8 88.8
Heating 88.1 92.8
Moisture removal pints/h (L/h) 2.7 (1.3) 3.8 (1.8)
Maximum operating current*
2
Cooling
A
6.9 6.9
Heating 9.4 9.4
Fan
Airflow rate
Cooling
HIGH
CFM (m
3
/h)
453 (770) 453 (770)
MED 353 (600) 353 (600)
LOW 265 (450) 265 (450)
QUIET 147 (250) 147 (250)
Heating
HIGH 453 (770) 453 (770)
MED 377 (640) 377 (640)
LOW 306 (520) 306 (520)
QUIET 182 (310) 182 (310)
Type × Q'ty Crossflow fan × 1
Motor output W 49
Sound pressure level*
3
Cooling
HIGH
dB (A)
43 43
MED 36 36
LOW 30 30
QUIET 19 19
Heating
HIGH 43 43
MED 38 38
LOW 33 33
QUIET 21 21
Heat exchanger type
Dimensions (H × W × D) in (mm)
Main1: 8-1/4 × 26-3/8 × 1-1/16 (210 × 670 × 26.6)
Main2: 4-7/16 × 26-3/8 × 13/16 (112 × 670 × 20)
Sub: 3-5/16 × 26-3/8 × 1/2 (84 × 670 × 13.3)
Fin pitch FPI
Man1: 21
Main2: 23
Sub: 18
Rows × Stages
Main1: 2 × 10
Main2: 2 × 7
Sub: 1 × 4
Pipe type Copper
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
in (mm)
10-5/8 × 32-13/16 × 8-3/4 (270 × 834 × 222)
Gross 10-7/8 × 36 × 13-1/16 (277 × 914 × 332)
Weight
Net
lb (kg)
22 (10)
Gross 29 (13)
Connection pipe
Size
Liquid
in (mm)
Ø 1/4 (6.35)
Gas Ø 3/8 (Ø 9.52)
Method Flare
Drain hose
Material PP+HDPE
Tip diameter in (mm) Ø17/32 (Ø 13.8) (I.D.), Ø19/32 to 21/32 (Ø 15.0 to 16.8) (O.D.)
Operation range
Cooling
°F (°C) 64 to 90 (18 to 32)
%RH 80 or less
Heating °F (°C) 60 to 86 (16 to 30)
Remote controller type
Wireless (Wired, Mobile app*
4
[FGLair
™
] [option])
- 2 -
1. Specifications
WALL MOUNTED ASUG09-12LMAS WALL MOUNTED ASUG09-12LMAS

Fujitsu AOUH12LMAH1 Specifications

General

Brand	Fujitsu
Model	AOUH12LMAH1
Category	Air Conditioner
Language	English
