Installation space requirement
Provide sufficient installation space for product safety.
CAUTION
Do not place any other electrical products or household belongings under the product. Conden-
sation dripping from the product might get them wet, and may cause damage or malfunction to
the property.
2-1/2 (63)
or more
3-8/1 (80)
or more
1-15/16 (50)
or more
1-15/16 (50)
or more
2-3/4 (70)
or more
Outline of unit
5-1/2 (140)
or more
59-1/16 (1,500) or more
70-7/8 (1,800) or more
Unit: in (mm)
- 5 -
2-1. Models: ASUH30LPAS and ASUH36LPAS
2. Dimensions
WALL MOUNTED
ASUH30-36LPAS
WALL MOUNTED
ASUH30-36LPAS
