DECORATION PANEL
UTG-UFYB-W
Flap total assy
Motor holder assy
182007.12.11
(connector : red)
(connector : white)
17
19
20
21
Ref. Description
17 Gear A 9375536015
19 Motor Holder 9375535018
20 Step Motor
(white connector)
9900139070
21 Step Motor
(red connector)
9900139087
Part number
