22007.12.10
OUTLINE AND DIMENSIONS
Unit : mm
DECORATION PANEL
700
30
49
700
570
245
146
75
30
102
135
250
99
40
Liquid pipe Gas pipe
108
INDOOR UNIT
TOP VIEW
SIDE VIEW
530
(
Hanging bolt position
)
Drain pipe
(I.D. / O
.D. 25.4
)
540
(
Hanging bolt position
)
