Fujitsu AOY30LMAW4 Service Manual

Total Pipe Length
FULL CHARGE
MODEL NAME
COOLING CAPACITY
HEATING CAPACITY
POWER SUPPLY
FREQUENCY
RUNNING CURRENT
INPUT
EER
AIR CIRCULATION HIGH
ELECTRICAL SPECIFICATIONS
(220) - 230 - (240) V
Cooling
Heating
Cooling
Heating
Cooling
Heating
TYPE
Cooling & heating multi
AOY30LMAW4
8.0 kW
9.6 kW
9.7 A
10.5 A
2.22 kW
2.40 kW
3.60 kW/kW
4.00 kW/kW
50 Hz
3,300 m3/hr
MAX PIPE LENGTH (each unit)
MAX PIPE LENGTH (total)
50 m
60 m
70 m
CHARGELESS
ADDITIONAL CHARGE
3,300 g
3,550 g
3,800 g
25 g/m
50 m
25 m
MIN. PIPE LENGTH (each unit)
5 m
70 m
MAX ELEVATION (between indoor units)
10 m
MAX ELEVATION (between indoor and outdoor) 10 m
OUTDOOR UNIT
COMPRESSOR AND REFRIGERANT
FAN MOTOR
MEASUREMENT
TYPE
DISCRIMINATION TNB220FPBMT
WEIGHT (with oil) 14.3 kg
STANDARD REFRIGERANT
REFRIGERANT TYPE
R410A
3,300 g
Hermetic type, Inverter,
4 poles, 3-phase,
DC motor, Twin Rotary
830 x 900 x 330 mm
78 kg / 68 kgWEIGHT
DIMENSIONS
MFE-60PO
820 r.p.m.
780 r.p.m.
H x W x D
Gross / Net
HIGH SPEED ( Cooling )
HIGH SPEED ( Heating )
DISCRIMINATION
22007.12.10

Fujitsu AOY30LMAW4 Specifications

General

Brand	Fujitsu
Model	AOY30LMAW4
Category	Air Conditioner
Language	English
