Fujitsu AOY30LMAW4 Service Manual

DECORATION PANEL
STANDARD ACCESSORIES
Name and Shape
2
4
4
1
1
1
2
2
For indoor side pipe joint
For air conditioner operation
For installing remote control
on the wall
For remote control
For mounting the remote
control holder
Q'ty
INDOOR UNIT
Name and Shape
Application
Coupler heat
insulation
Special nut A
(large flange)
Special nut B
(small flange)
Template
(Carton top)
For installing indoor unit
For installing indoor unit
For cealing openings cutting
Also used as packing
4
4
1
For covering connector
Q'ty
Name and Shape
Application
Connector cover
Screw
Screw
For mounting decoration panel
For mounting connector cover
272007.12.11
Remote
control
holder
Remote
control
Battery
Tapping screw
OPTIONAL PARTS
UTB-* YD
UTR-YDZB
Summary
Unit control is performed by
wired remote control.
Install the plate at outlet
when carrying out 3-way
direction operation.
Wired remote
control
Air outlet
shutter plate
