14
16
15
12
13
11
OUTDOOR UNIT
2010.01.15 24
15 Propeller Fan Assy 9366378020
-- Valve Plate 9374099030
16
Motor Bracket Sub Assy
9374418152
14 Fan Motor 9602843015
12 Condenser A Assy 9374433056
13
Separate Wall Sub Assy
9374413188
11 Base Assy 9374166138
Ref. Part numberDescription
