43
49
48
44
42
41
46
47
45
INDOOR UNIT
Control box
15
47
Display PCB Assy
9707649024
46
Display Case
9316587007
48
Terminal
9900638009
45
Controller PCB Assy (07)
9708536156
45
Controller PCB Assy (09)
9708536163
--
Thermistor Assy
9900563004
49
Earth Terminal
9316586000
41
Control Box
9316582002
42
Box Shield
9316580008
43
Control Cover
9316583009
44
Cover Shield
9316581005
Ref.
Description
Part number
2011.01.24
15
17
Table of Contents
Table of Contents
1
Wall Mounted Type
1
Specifications
2
Dimensions
3
Refrigerant System Diagram
4
Circuit Diagram
5
Indoor Pcb Circuit Diagram
6
R202 C203
8
Outdoor Pcb Circuit Diagram
10
Error Detection
12
Parts (Indoor Unit)
14
Parts (Outdoor Unit)
18
Accessories
21
