53
56
54
55
52
57
16
51
Evaporator Total Assy
9316893009
52
Joint Pipe Assy
9316923010
53
Filter Guide
9316578005
55
54
Evaporator Holder R
9316565005
56
Evaporator Holder L
9316564008
Rear Bracket
9316566019
57
Room Thermistor Holder
9316895003
Ref.
Description
Part number
INDOOR UNIT
Evaporator
2011.01.24
51
16
18
Table of Contents
Table of Contents
1
Wall Mounted Type
1
Specifications
2
Dimensions
3
Refrigerant System Diagram
4
Circuit Diagram
5
Indoor Pcb Circuit Diagram
6
R202 C203
8
Outdoor Pcb Circuit Diagram
10
Error Detection
12
Parts (Indoor Unit)
14
Parts (Outdoor Unit)
18
Accessories
21
