Item no. Part no. Part name Service part
1 9322556028 Top panel assy ♦
2 9322811011 Protective net assy ♦
3 9322552020 Cabinet right assy ♦
4 9322570000 Switch cover assy ♦
5 9709687130 Main PCB ♦
6 9900727062 Thermistor assy ♦
7 9900850012 Thermistor (Outdoor temp.) ♦
8 9900583019 Reactor assy ♦
9 9322314000 Base assy ♦
10 9322144003 Drain pipe ♦
11 9322555014 Front panel assy ♦
12 9322135001 Blow grille ♦
13 0700103070 Nut ♦
14 9322136008 Propeller fan ♦
15 9603553005 DC fan motor ♦
16 9322553010 Motor bracket assy ♦
17 9323834019 Heat exchanger unit ♦
a — Hair pin cushion —
3-2. Model: AOYG14KMCC - (02-11) - 3. Outdoor unit parts list
