PARTS
INDOOR UNIT
ASYG07LMCE
ASYG09LMCE
2016.11.07 9
6
7 Screw Cap 9309002074
3 Bracket Panel 9332882025
4 Electric Filter Holder 9332911008
5 Air Clean Filter Assy 9317250009
1 Remote Control 9319208008
2 Remote Control Holder 9318912005
Ref. Description Part number
Air Filter 9332875010
5
4
6
3
1
2
7
