INDOOR UNIT
ASYG07LMCE
ASYG09LMCE
Casing assy
15
Step Motor 990079000463
Step Motor 990079001164
62
61
Cable Guide 9332903003
Motor Holder L/R 9332859003
Ref. Description Part number
2016.11.07
63
62
61
61
64
