Fujitsu AOYG12KMTA Design & Technical Manual

4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and
the indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
¢
Model: ASYG07KMTA
AFR
m
3
/h
650
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10 2.72 2.51 0.35 2.96 2.60 0.35 3.12 2.67 0.34 3.28 2.73 0.34 3.35 2.81 0.34 3.59 2.86 0.34 3.83 2.95 0.33
0 2.65 2.45 0.39 2.89 2.54 0.39 3.04 2.60 0.39 3.19 2.66 0.38 3.26 2.74 0.39 3.50 2.79 0.38 3.73 2.88 0.37
5 2.51 2.38 0.53 2.72 2.47 0.52 2.87 2.53 0.52 3.01 2.59 0.52 3.08 2.67 0.52 3.31 2.72 0.51 3.52 2.81 0.50
10 2.58 2.36 0.50 2.80 2.45 0.49 2.95 2.51 0.49 3.10 2.57 0.49 3.17 2.64 0.49 3.40 2.69 0.48 3.62 2.78 0.47
15 2.52 2.37 0.49 2.74 2.46 0.49 2.89 2.52 0.49 3.03 2.58 0.48 3.10 2.66 0.49 3.32 2.70 0.48 3.54 2.79 0.47
20 2.45 2.36 0.50 2.66 2.45 0.50 2.80 2.51 0.50 2.95 2.57 0.49 3.01 2.65 0.50 3.23 2.69 0.49 3.44 2.78 0.48
25 2.36 2.34 0.53 2.57 2.43 0.53 2.70 2.49 0.52 2.84 2.55 0.52 2.90 2.62 0.52 3.11 2.66 0.51 3.32 2.75 0.51
30 2.26 2.30 0.57 2.45 2.38 0.57 2.59 2.44 0.56 2.72 2.50 0.56 2.78 2.57 0.56 2.98 2.62 0.55 3.17 2.70 0.55
35 2.14 2.24 0.63 2.33 2.32 0.62 2.45 2.38 0.62 2.57 2.43 0.62 2.63 2.50 0.62 2.82 2.55 0.61 3.01 2.63 0.60
40 2.00 2.16 0.70 2.18 2.24 0.70 2.30 2.30 0.69 2.41 2.35 0.69 2.46 2.42 0.69 2.64 2.46 0.68 2.82 2.54 0.67
46 1.82 2.04 0.81 1.98 2.12 0.80 2.09 2.17 0.80 2.19 2.22 0.79 2.24 2.29 0.80 2.40 2.33 0.78 2.56 2.41 0.77
¢
Model: ASYG09KMTA
AFR
m
3
/h
700
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10 2.79 2.57 0.35 3.04 2.67 0.35 3.20 2.73 0.35 3.36 2.80 0.34 3.43 2.88 0.35 3.68 2.93 0.34 3.93 3.03 0.34
0 2.72 2.51 0.40 2.96 2.60 0.39 3.12 2.67 0.39 3.27 2.73 0.39 3.35 2.81 0.39 3.59 2.86 0.38 3.83 2.95 0.38
5 2.57 2.44 0.53 2.79 2.54 0.53 2.94 2.60 0.52 3.09 2.66 0.52 3.16 2.74 0.52 3.39 2.78 0.51 3.61 2.88 0.51
10 2.64 2.42 0.50 2.87 2.51 0.50 3.02 2.57 0.49 3.18 2.63 0.49 3.25 2.71 0.49 3.48 2.76 0.48 3.71 2.85 0.48
15 2.58 2.43 0.50 2.81 2.52 0.49 2.96 2.58 0.49 3.11 2.65 0.49 3.18 2.72 0.49 3.41 2.77 0.48 3.63 2.86 0.47
20 2.51 2.42 0.51 2.73 2.51 0.50 2.88 2.58 0.50 3.02 2.64 0.50 3.09 2.71 0.50 3.31 2.76 0.49 3.53 2.85 0.49
25 2.42 2.40 0.54 2.63 2.49 0.53 2.77 2.55 0.53 2.91 2.61 0.52 2.98 2.68 0.53 3.19 2.73 0.52 3.40 2.82 0.51
30 2.32 2.35 0.58 2.52 2.44 0.57 2.65 2.50 0.57 2.79 2.56 0.56 2.85 2.64 0.57 3.05 2.68 0.56 3.26 2.77 0.55
35 2.19 2.29 0.64 2.38 2.38 0.63 2.51 2.44 0.63 2.64 2.50 0.62 2.70 2.57 0.63 2.89 2.61 0.61 3.08 2.70 0.61
40 2.06 2.21 0.71 2.23 2.30 0.70 2.35 2.35 0.70 2.47 2.41 0.69 2.53 2.48 0.70 2.71 2.52 0.68 2.89 2.61 0.68
46 1.87 2.09 0.82 2.03 2.17 0.81 2.14 2.23 0.80 2.25 2.28 0.80 2.30 2.35 0.80 2.46 2.39 0.79 2.63 2.47 0.78
¢
Model: ASYG12KMTA
AFR
m
3
/h
700
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10 3.41 2.90 0.48 3.70 2.99 0.48 3.89 3.04 0.48 4.09 3.10 0.48 4.20 3.17 0.47 4.47 3.22 0.47 4.76 3.31 0.47
0 3.18 2.78 0.63 3.45 2.86 0.62 3.63 2.92 0.62 3.81 2.97 0.62 3.92 3.04 0.61 4.17 3.09 0.61 4.44 3.17 0.61
5 3.02 2.70 0.73 3.28 2.78 0.72 3.45 2.84 0.72 3.62 2.90 0.72 3.72 2.96 0.71 3.96 3.01 0.71 4.21 3.09 0.70
10 3.30 2.91 0.55 3.58 3.00 0.54 3.77 3.06 0.54 3.96 3.12 0.54 4.07 3.18 0.53 4.33 3.24 0.53 4.61 3.32 0.53
15 3.23 2.81 0.60 3.50 2.89 0.60 3.68 2.95 0.59 3.87 3.01 0.59 3.98 3.07 0.58 4.23 3.12 0.59 4.50 3.21 0.58
20 3.13 2.72 0.66 3.40 2.80 0.65 3.58 2.86 0.65 3.75 2.91 0.65 3.86 2.97 0.64 4.11 3.02 0.64 4.37 3.10 0.64
25 3.02 2.64 0.72 3.27 2.72 0.72 3.44 2.78 0.71 3.61 2.83 0.71 3.72 2.89 0.70 3.95 2.94 0.70 4.21 3.02 0.70
30 2.88 2.58 0.79 3.13 2.66 0.78 3.29 2.71 0.78 3.45 2.76 0.78 3.55 2.82 0.77 3.78 2.87 0.77 4.02 2.95 0.76
35 2.73 2.53 0.86 2.96 2.61 0.86 3.11 2.66 0.85 3.26 2.71 0.85 3.36 2.77 0.84 3.57 2.82 0.84 3.80 2.89 0.83
40 2.55 2.50 0.94 2.76 2.57 0.93 2.91 2.62 0.93 3.05 2.68 0.92 3.14 2.73 0.91 3.34 2.78 0.92 3.56 2.85 0.91
46 2.31 2.47 1.04 2.51 2.55 1.03 2.64 2.60 1.03 2.77 2.65 1.02 2.85 2.71 1.01 3.03 2.75 1.01 3.22 2.83 1.01
- 7 -
WALL MOUNTED ASYG07-14KMTA

Fujitsu AOYG12KMTA Specifications

General

Type	Air conditioner outdoor unit
Multi-split	No
Product color	White
Gas hose diameter	9.5 mm
Hose length (max)	15 m
Inverter technology	Yes
Liquid hose diameter	6.35 mm
Refrigerating medium	R32
Air conditioner functions	Cooling, Heating
Refrigerating medium weight	700 g
Cooling capacity in watts (nominal)	- W
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)	-
AC input voltage	230 V
Current (cooling)	6.5 A
Current (heating)	9 A
AC input frequency	50 Hz
Design load (cooling)	- kW
Hourly energy consumption (cooling)	- kWh
Indoor unit noise level (high speed)	- dB
Outdoor unit depth	290 mm
Outdoor unit width	663 mm
Outdoor unit height	541 mm
Outdoor unit weight	25000 g
Outdoor units quantity	1
Outdoor unit noise level	58 dB
Cooling airflow (outdoor unit)	770 m³/h
Outdoor unit sound power level	50 dB
