4-2. Heating capacity
NOTE:
Values mentioned in the table are calculated based on the maximum capacity.
¢
Model:ASYG07LMCE
AFR
m
3
/h
750
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 1.72 0.71 1.68 0.73 1.64 0.74 1.60 0.75 1.56 0.77
-10 -11 2.38 0.86 2.33 0.88 2.27 0.90 2.21 0.92 2.16 0.94
-5 -7 2.90 0.97 2.83 0.99 2.76 1.01 2.69 1.03 2.62 1.05
0 -2 3.18 1.02 3.10 1.04 3.03 1.06 2.95 1.08 2.87 1.10
5 3 3.46 1.06 3.38 1.09 3.29 1.11 3.21 1.13 3.13 1.15
7 6 3.57 1.08 3.49 1.10 3.40 1.13 3.32 1.15 3.23 1.17
10 8 3.98 1.19 3.88 1.21 3.79 1.24 3.69 1.26 3.60 1.29
15 10 3.72 1.09 3.63 1.12 3.54 1.14 3.45 1.16 3.36 1.18
¢
Model:ASYG09LMCE
AFR
m
3
/h
750
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 1.72 0.71 1.68 0.73 1.64 0.74 1.60 0.75 1.56 0.77
-10 -11 2.38 0.86 2.33 0.88 2.27 0.90 2.21 0.92 2.16 0.94
-5 -7 2.99 0.97 2.91 0.99 2.84 1.01 2.77 1.03 2.70 1.05
0 -2 3.49 1.02 3.41 1.04 3.33 1.06 3.24 1.08 3.16 1.10
5 3 4.00 1.06 3.90 1.09 3.81 1.11 3.71 1.13 3.62 1.15
7 6 4.20 1.08 4.10 1.10 4.00 1.13 3.90 1.15 3.80 1.17
10 8 4.76 1.19 4.65 1.21 4.53 1.24 4.42 1.26 4.31 1.29
15 10 4.53 1.09 4.42 1.12 4.31 1.14 4.20 1.16 4.10 1.18
¢
Model:ASYG12LMCE
AFR
m
3
/h
750
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 2.94 1.54 2.87 1.57 2.80 1.60 2.73 1.63 2.66 1.66
-10 -11 3.73 1.60 3.64 1.63 3.55 1.67 3.46 1.70 3.37 1.73
-5 -7 4.40 1.62 4.29 1.65 4.19 1.69 4.08 1.72 3.98 1.75
0 -2 4.88 1.57 4.77 1.60 4.65 1.64 4.53 1.67 4.42 1.70
5 3 5.37 1.52 5.24 1.56 5.11 1.59 4.99 1.62 4.86 1.65
7 6 5.57 1.51 5.43 1.54 5.30 1.57 5.17 1.60 5.04 1.63
10 8 5.85 1.51 5.71 1.54 5.57 1.57 5.43 1.60 5.29 1.63
15 10 5.66 1.39 5.52 1.42 5.39 1.45 5.25 1.48 5.12 1.51
¢
Model:ASYG14LMCE
AFR
m
3
/h
770
Indoor temperature
16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 3.65 1.43 3.57 1.46 3.48 1.49 3.39 1.52 3.31 1.55
-10 -11 4.29 1.51 4.19 1.54 4.09 1.57 3.99 1.60 3.89 1.63
-5 -7 4.68 1.58 4.57 1.61 4.46 1.64 4.34 1.68 4.23 1.71
0 -2 5.31 1.69 5.19 1.72 5.06 1.76 4.93 1.79 4.81 1.83
5 3 5.73 1.79 5.59 1.83 5.46 1.86 5.32 1.90 5.18 1.94
7 6 6.30 1.86 6.15 1.89 6.00 1.93 5.85 1.97 5.70 2.01
10 8 6.64 1.90 6.49 1.94 6.33 1.98 6.17 2.02 6.01 2.06
15 10 6.44 1.65 6.28 1.69 6.13 1.72 5.98 1.76 5.82 1.79
DESIGN & TECHNICAL MANUAL
- 8 -
WALL MOUNTED ASYG07-14LMCE
