INDOOR UNIT
25
21
25 2 Stage Turbo Fan Assy 9375480011
24 Turbo Fan Washer 9375487010
22
Evaporator Total Assy (12) 9377914033
22
Evaporator Total Assy (14, 18)
9377914026
23 Evaporator Holder
9375508012
26 Fan Motor 9602436019
21 Separate Wall 9375506018
Ref. Description Part number
27 Fan Motor Holder 9375552015
31 Float Switch 9900361037
32 Drain Port Sub Assy 9375718015
30 Rubber (Pump) 9378426016
28 Pump Assy
9900472030
29 Drain Pump Holder B 9375518011
Ref. Description Part number
172011.12.09
22
23
23
27
26
31
28
32
30
29
24
To Next Page
