Installation space requirement
Provide sufficient installation space for product safety.
Unit: mm
Wall hook bracket
Outline of the indoor unit
65 or more
83 or more
52 or more
48 or more
70 or more
1,500 or more
1,800 or more
85 or more
The flare connection
part should be installed
outdoors.
- 5 -
2-1. Models: ASYG18KLCA and ASYG24KLCA 2. Dimensions
WALL MOUNTED ASYG18, 24KLCA WALL MOUNTED ASYG18, 24KLCA
