Fujitsu AOYG18LFC Service Manual

12011.02.17
SPECIFICATIONS
INDOOR UNIT
OUTDOOR UNIT
COOLING CAPACITY
POWER SOURCE
FREQUENCY
RUNNING CURRENT (Cool)
INPUT WATTS (Cooling)
E.E.R. (Cooling)
MOISTURE REMOVAL
AIR CIRCULATION HIGH
ASYG18LFCA
AOYG18LFC
5.20 kW
HEATING CAPACITY 6.30 kW
230 V
50 Hz
6.8 A
RUNNING CURRENT (Heat)
7.6 A
MAXIMUM CURRENT (Heat)
12.5 A
MAXIMUM CURRENT (Cool)
9.0 A
1.52 kW
3.42 kW/kW
INPUT WATTS (Heating)
C.O.P. (Heating)
1.71 kW
3.68 kW/kW
2.6 L/hr
900 m
3
/hr
ELECTRICAL DATA COMPRESSOR AND REFRIGERANT
FAN MOTOR
DIMENSIONS
TYPE
REFRIGERANT TYPE
Hermetic type,
4 pole, Rotary,
DC inverter motor
DISCRIMINATION
PRECHARGED REFRIGERANT
R410A
WEIGHT (with oil)
9.0 kg
808 903 80
POWER SOURCE
High
870 r.p.m.
920 r.p.m.
230 V
1,220 r.p.m.
1,020 r.p.m.
900 r.p.m.
710 r.p.m.
Medium
Low
Quiet
Cool
Heat
OUTDOOR UNIT
INDOOR UNIT
H x W x D
H x W x D
OUTDOOR UNIT
WEIGHT
INDOOR UNIT
Shipping / Net
Shipping / Net
18 kg / 14 kg
OUTDOOR UNIT
45 kg / 41 kg
320 x 998 x 238 mm
620 x 790 x 290 mm
NOISE LEVEL
High
43 dB
37 dB
33 dB
26 dB
51 dB
INDOOR UNIT
(Cooling)
INDOOR UNIT
Medium
Low
Quiet
High
42 dB
37 dB
33 dB
25 dB
INDOOR UNIT
(Heating)
Medium
Low
Quiet
15 m
20 m
25 m
OUTDOOR UNIT (Heat)
50 dB OUTDOOR UNIT (Cool)
FULL CHARGE
Pipe Length
1,200 g
1,200 g
20 g/m
20 m
ADDITIONAL CHARGE
MAX HEIGHT
1,300 g
1,400 g

Fujitsu AOYG18LFC Specifications

General

Brand	Fujitsu
Model	AOYG18LFC
Category	Air Conditioner
Language	English
