INDOOR UNIT
13
14 Control Box 9358600054
-- Room Thermistor 9703299087
16 Main PCB 9709245378
15
Control Box Cover Assy
9359097006
18 Terminal 3P 9306489045
19 Terminal 3P 9703345012
970739827417 Power Supply PCB
Ref. Description Part number
2013.03.26
12 Cap 9358563007
13 Base Bracket 9358586006
11 Base Assy 9359061014
15
17
18
14
16
19
12
12
13
12
12
11
