PARTS
INDOOR UNIT
12
8
4
4
7
3
6
5
1
2
5 Hanger Bracket L 9358596005
6 Hanger Bracket R 9358595008
7 Cosmetic Panel R 9358535028
8 Cosmetic Panel L 9358536025
1 Remote Control 9379219037
2
Remote Control Holder
9305642045
3 Top Cover 9358534021
4 Arm 9358565001
Ref. Description Part number
2012.04.24
