2013.03.20 19
2
10
1
7
11
6
4
5
9
OUTDOOR UNIT
PARTS
8
2 Top Panel Assy
4 Cabinet
5 Blow Down Grille
11 Cabinet Right Assy
6 Fan Ring
7 Grip
1 Protective Net
8 Emblem
10 Switch Cover Assy
9309230057
9314809019
3 Cabinet Assy 9312799459
9309237032
9308884015
9309236028
9308885012
9308880017
9315033017
9319151007
9 Fan Guard Cover 9378110014
Ref. Description Part number
16 Propeller Fan
17 Nut With Washer
15 Fan Motor
Reactor Assy14
9309909014
9304902003
13 Drain Assy 9303029015
9602451012
9900354015
14
12
13
17
15
16
12 Base Assy 9315296030
3
21
20
18
19
Terminal19
18 Main PCB
9703874031
Heat Sink A20 9314410017
Heat Sink B21 9314090011
9707427561
