Fujitsu AOYG24LALA User Manual

2013.02.19 20
OUTDOOR UNIT
35 4-way Valve Assy
41 Pulse Motor Valve Assy
31 Condenser Total Assy
39 3-way Valve Assy
40 2-way Valve Assy
42 Expansion Valve Coil
32 Compressor Assy
34 Solenoid Coil
Thermistor Assy--
-- Heat Exchanger Thermistor
Outdoor Thermistor--
Ref. Description Part number
33 Compressor Thermistor
9315311023
9315310019
9312322091
9900403010
9315414014
9313062019
38 3WV Joint Pipe Assy
37 Suction Pipe Assy
36 Discharge Pipe Assy
9315308023
9315313027
9315312020
9900057039
9315297037
9970055010
9900148027
9900210045
9900156046
35
42
31
32
33
39
41
37
36
38
34
40
