DIMENSIONS
Unit : mm
INDOOR UNIT
2013.02.20 2
Drain pipe
mounting place
( 20)
189
177
347
540
315
66
790
121
578
320
10
184
4- 10mm hole
OUTDOOR UNIT
Air flow
990
900
500
655
530
200175
199
