4. Refrigerant circuit
4-1. Models: AOYG36KBTB, AOYG45KBTB, and AOYG54KBTB
2-Way
valve
Strainer
Strainer
3-Way
valve
4-Way valve
Expansion valve
Heat exchanger
( INDOOR )
Heat exchanger
( OUTDOOR )
Co
mpre
s
so
r
: Cooling
: Heating
Pressure
switch
Su
b
-accumulator
Th
C
Th
R
Th
D
Th
PI
Th
O
Th
HO
Th
C
:
Thermistor (Compressor temperature)
: Thermistor (Discharge temperature)
: Thermistor (Outdoor temperature)
: Thermistor (Heat Exchanger Out temperature)
Th
D
Th
O
Th
H
O
: Thermistor (Room temperature)
: Thermistor (Pipe temperature)
Th
R
Th
PI
Pressure
sensor
- 62 -
4-1. Models: AOYG36KBTB, AOYG45KBTB, and AOYG54KBTB 4. Refrigerant circuit
OUTDOOR UNIT
AOYG36-54KBTB
OUTDOOR UNIT
AOYG36-54KBTB
