Fujitsu AOYG36KBTB - Page 76

¢
Heating capacity (Twin)

Compact cassette type
Model: AUXG22KVLA × 2
AFR
m
3
/h
1,720
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 10.89 4.34 10.63 4.36 10.37 4.38 10.13 4.43 9.53 4.56
-10 -11 12.10 4.52 11.81 4.54 11.52 4.57 11.25 4.62 10.58 4.75
-5 -7 13.30 4.71 12.99 4.73 12.67 4.75 12.37 4.81 11.64 4.94
0 -2 14.53 4.89 14.18 4.92 13.83 4.94 13.51 5.00 12.71 5.14
5 3 15.55 4.56 15.18 4.58 14.81 4.61 14.46 4.66 13.60 4.79
7 6 15.96 4.55 15.58 4.58 15.20 4.60 14.85 4.65 13.96 4.78
10 8 16.62 4.54 16.23 4.57 15.83 4.59 15.46 4.64 14.54 4.77
15 10 17.73 4.53 17.30 4.55 16.88 4.57 16.49 4.63 15.51 4.76
20 15 18.83 4.51 18.38 4.53 17.93 4.56 17.51 4.61 16.47 4.74
24 18 19.71 4.50 19.24 4.52 18.77 4.54 18.33 4.59 17.24 4.72

Du
ct type
Model: ARXG22KMLA × 2
AFR
m
3
/h
2,200
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 10.89 4.34 10.63 4.36 10.37 4.38 10.13 4.43 9.53 4.56
-10 -11 12.10 4.52 11.81 4.54 11.52 4.57 11.25 4.62 10.58 4.75
-5 -7 13.30 4.71 12.99 4.73 12.67 4.75 12.37 4.81 11.64 4.94
0 -2 14.53 4.89 14.18 4.92 13.83 4.94 13.51 5.00 12.71 5.14
5 3 15.55 4.56 15.18 4.58 14.81 4.61 14.46 4.66 13.60 4.79
7 6 15.96 4.55 15.58 4.58 15.20 4.60 14.85 4.65 13.96 4.78
10 8 16.62 4.54 16.23 4.57 15.83 4.59 15.46 4.64 14.54 4.77
15 10 17.73 4.53 17.30 4.55 16.88 4.57 16.49 4.63 15.51 4.76
20 15 18.83 4.51 18.38 4.53 17.93 4.56 17.51 4.61 16.47 4.74
24 18 19.71 4.50 19.24 4.52 18.77 4.54 18.33 4.59 17.24 4.72
- 68 -
6-2. Model: AOYG45KBTB 6. Capacity table
OUTDOOR UNIT AOYG36-54KBTB OUTDOOR UNIT AOYG36-54KBTB
