WALL MOUNTED ASYG30, 36LMTA
3. Specifications
Type
Wall mounted
Inverter heat pump
Model name
ASYG30LMTA ASYG36LMTA
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 8.00 9.40
Btu/h 27,300 32,100
Min.—Max.
kW 2.9—9.0 2.9—10.0
Btu/h 9,900—30,700 9,900—34,100
Heating
Rated
kW 8.80 10.10
Btu/h 30,000 34,500
Min.—Max.
kW 2.2—11.0 2.7—11.2
Btu/h 7,500—37,500 9,200—38,200
Input power
Cooling
Rated
kW
2.33 3.16
Min.—Max. 0.50—3.30 0.50—4.33
Heating
Rated 2.41 2.96
Min.—Max. 0.50—3.30 0.50—4.33
Fan
HIGH
W
60 60
MED 35 35
LOW 20 20
QUIET 11 11
Current
Cooling
Rated A
10.2 13.9
Heating 10.5 13.0
EER Cooling
kW/kW
3.43 2.97
COP Heating 3.65 3.41
Sensible capacity Cooling kW 1.85 2.55
Power factor
Cooling
%
99 99
Heating 99 99
Moisture removal L/h (pints/h) 2.7 (4.8) 3.7 (6.5)
Maximum operating current *1
Cooling
A
14.5 19.0
Heating 14.5 19.0
Fan
Airflow rate
Cooling
HIGH
m
3
/h
1,380 1,380
MED 1,130 1,130
LOW 910 910
QUIET 710 710
Heating
HIGH 1,380 1,380
MED 1,130 1,130
LOW 910 910
QUIET 710 710
Type × Q'ty Cross flow fan × 1
Motor output W 61
Sound pressure level *2
Cooling
HIGH
dB(A)
50 50
MED 44 44
LOW 38 38
QUIET 31 31
Heating
HIGH 49 49
MED 44 44
LOW 39 39
QUIET 33 33
Heat exchanger type
Dimensions (H × W × D)
mm
Main: 462 × 900 × 26.6
Sub1: 126 × 900 × 13.3
Sub2: 84 × 900 × 13.3
Fin pitch 1.2
Rows × Stages Main: 2 × 22, Sub1: 1 × 6, Sub2: 1 × 4
Pipe type Copper tube
Fin type Aluminum
Enclosure
Material Polystyrene
Color
White
Approximate color of Munsell N 9.25/
Dimensions
(H × W × D)
Net
mm
340 × 1,150 × 280
Gross 450 × 1,270 × 405
Weight
Net
kg
18
Gross 24
Connection pipe
Size
Liquid
mm (in)
Ø 9.52 (Ø 3/8)
Gas Ø 15.88 (Ø 5/8)
Method Flare
Drain hose
Material PVC
Size mm Ø 13.8 (I.D.), Ø 15.8 to Ø 16.7 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wireless (Wired [option])
NOTES:
Specifications are based on the following conditions:
–Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
–Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
–Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
Protective function might work when using it outside the operation range.
*1: Maximum current is maximum value when operated within the operation range.
*2: Sound pressure level:
–Measured values in manufacturer’s anechoic chamber.
–Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
