- 14 -
WALL MOUNTED
ASYG30, 36LMTA
4. Dimensions
Unit: mm
1150
Outline of unit
520
90
21
64
47961 108502
520
50
50
11
340
ø80
ø80
340
280
16
1150
609
672
725
