- 30 -
WALL MOUNTED
ASYG30, 36LMTA
Input signal type
• Indoor unit
Input signal type is only "Edge".
• External input and output PCB
The input signal type can be selected.
Signal type (edge or pulse) can be switched by the DIP switch SW302 on the External input and
output PCB.
Edge
Edge
Pulse
The width of pulse must be longer than 200 msec.
