¢ Panels
Decoration Panel
Corner Panel Assy
Drain Cover Assy
9381713004
9381352005
9381711000
Parts No.
Description
Ref
No.
11
12
13
11
13
12
2-1. Model: UTG-UKYC-W - (02-3) - 2. Cassette grille (optional part) parts list
TECHNICAL DATA
AND PARTS LIST
TECHNICAL DATA
AND PARTS LIST
