Fujitsu AOYG45KATA - Models: AOYG30 KATA, AOYG36 KATA, AOYG45 KATA, and AOYG54 KATA

7-2. Models: AOYG30KATA, AOYG36KATA, AOYG45KATA, and
AOYG54KATA
-Way
valve
Strainer
Strainer
3-Way
valve
4-Way valve
Expansion valve
Heat exchanger
( INDOOR )
Heat exchanger
( OUTDOOR )
Co
mpre
s
so
r
: Cooling
: Heating
Pressure
switch
Su
b
-accumulator
Th
C
Th
R
Th
D
Th
PI
Th
O
Th
HO
Th
C
: Thermistor (Compressor temperature)
: Thermistor (Discharge temperature)
: Thermistor (Outdoor temperature)
: Thermistor (Heat Exchanger Out temperature)
Th
D
Th
O
Th
HO
: Thermistor (Room temperature)
: Thermistor (Pipe temperature)
Th
R
Th
PI
3
7-2. Models: AOYG30KATA, AOYG36KATA, AOYG45KATA, and AOYG54KATA - (02-29) - 7. Refrigerant system diagrams
