¢ Evaporator

Insulation Box Sub Assy (30,36,45,54)

Pipe cover

43 Wind Guide Board 9382125004

9378580664

Cabinet B sub assy

Cabinet A L

9381787005

Top plate assy

Evaporator holder

Ref. Description

Part number

Evaporator Total Assy (24)

42 9378580688Evaporator Total Assy (36,45,54)

Insulation Box Sub Assy (24)41

9381787012

42 9378580671Evaporator Total Assy (30)

3-1. Models: AUXG24KRLB, AUXG30KRLB, AUXG36KRLB, AUXG45KRLB, and

AUXG54KRLB

- (02-9) - 3. Indoor unit parts list

TECHNICAL DATA

AND PARTS LIST

TECHNICAL DATA

AND PARTS LIST
