- 132 -
OUTDOOR UNIT
AOYG12-54LB
13. Function settings
Perform appropriate function setting locally according to the installation environment.
NOTE: Incorrect settings can cause a product malfunction.
• Before setting up the switch buttons, discharge the static electricity from your body.
• Never touch the terminals or the patterns on the parts that are mounted on the PCB.
13-1. Local setting switch buttons
Control PCB and switch buttons location
Control PCB of the outdoor unit is located as shown in the following figure.
Models: AOYG45LBTA and AOYG54LBTA
Terminal block
Switch buttons
LED lamps
To Next Page
