OUTDOOR UNIT AOYG12-54LB
1. Specifications
1-1. Models: AOYG12LBLA and AOYG14LBLA
Type
Inverter heat pump
Model name
AOYG12LBLA AOYG14LBLA
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Starting current A4.75.7
Fan
Airflow rate
Cooling
m
3
/h
1,780 1,910
Heating 1,630 1,740
Type × Q'ty Propeller × 1
Motor output W 40
Sound pressure level *1
Cooling
dB (A)
47 49
Heating 48 49
Sound power level
Cooling
dB (A)
60 64
Heating 61 63
Heat exchanger type
Dimensions (H × W × D)
mm
Main:546 × 876 × 18.2
Sub:546 × 842 × 18.2
Fin pitch 1.30
Rows × Stages 2 × 26
Pipe type Copper
Fin
Type (Material) Corrugate (Aluminum)
Surface treatment Hydrophilic coating
Compressor
Type × Q'ty Twin rotary × 1
Motor output W 1,100
Refrigerant
Type R410A
Factory charge g 1,150 1,250
Refrigerant oil
Type POE (VG74)
Amount
cm
3
450
Enclosure
Material Steel
Color
Beige
Approximate color of MUNSELL 10YR7.5/1.0
Dimensions
(H × W × D)
Net
mm
578 × 790 × 300
Gross 648 × 910 × 380
Weight
Net
kg
40
Gross 44
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4) Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8) Ø 12.70 (Ø 1/2)
Method Flare
Pre-charge length
m
15
Max. length 25
Max. height difference 15
Operation range
Cooling
°C
-10 to 46
Heating -15 to 24
NOTES:
Specifications are based on the following conditions:
–Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
–Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
–Pipe length: 5 m, Height difference: 0 m.
Protective function might work when using it outside the operation range.
*1: Sound pressure level
–Measured values in manufacturer’s anechoic chamber.
–Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
