Fujitsu AR*9LUAB

4. FRONT PANEL removal
Remove the 4 mounting screws.
Remove the FRONT PANEL by sliding upward.
06-06
Hook
(2 places)
Hook
(2 places)
Hook
FRONT PANEL
VALVE COVER
5. VALVE COVER removal
Remove the VALVE COVER.
Replaceable Component
Compressor
Accumulator
Solenoid
Thermistor (Discharge temp.)
Thermistor (Outdoor temp.)
PTC Thermistor
Pressure SW
Coil (Expansion valve)
Fan motor & Fan
